Research on The Influence of Stator, Magnet And Winding on Motor Performance

In FPV drone power systems, motor performance directly determines the upper limit of the aircraft’s overall performance. Motors with the same size and KV value often show huge differences in actual performance. The root cause lies in the differences in stator structure, magnet material and grade, as well as winding technology and turns.

1. Introduction

•    Higher power density and lower heat generation

•    More linear power output

•    Longer service life and higher reliability

•    Scenario-based performance suitable for racing, freestyle and long-range flight

      Therefore, the optimal matching of stator, magnet and winding is the core of high-end FPV motor development.

2. Influence of the Stator on Motor Performance

2.1 Stator Size

•    Stator diameter: determines the core cross-sectional area and winding space. Larger diameter means higher power potential and torque upper limit.

•    Stator height: determines winding space and turns. Greater height provides stronger torque and continuous output capability.

2.2 Stator Material and Technology

•    Silicon steel sheet material and lamination technology: affect iron loss, heat generation, efficiency and high-speed stability.

•    Insulation treatment: determines the motor’s high temperature resistance, high voltage resistance and aging resistance, which directly affect reliability and service life.

2.3 Key Functions of the Stator

•    Determines the maximum continuous current and peak power.

•    Affects low-speed torque, high-speed efficiency and heat generation.

•    Determines structural strength and crash resistance.



•    In short: The stator defines the foundation and upper limit of motor performance.













• 3. Influence of the Magnet on Motor Performance

•       The magnet is the magnetic field source of the motor, a key variable for power and efficiency.

• 3.1 Magnet Performance Grade

•    Higher magnetic energy product (such as N52 and above) provides stronger magnetic field strength.

•    Stronger magnetic field delivers greater torque, faster response, higher efficiency and more stable high-speed performance.

• 3.2 Demagnetization Resistance

•    High temperature resistance and demagnetization resistance determine the service life under violent working conditions.

•    No power attenuation under long-term high temperature is a core indicator of high-end motors.

• 3.3 Magnet Size and Arrangement

•    Thickness, width and pole ratio affect torque curve, linearity and cogging torque.

• 3.4 Key Functions of the Magnet

•    Determines torque output and response speed.

•    Affects efficiency, heat generation and high-speed stability.

•    Determines whether power attenuates during long-term use.

•    In short: The magnet defines strength, deciding whether the motor is powerful, stable and durable.








• 4. Influence of the Winding on Motor Performance

•    The winding is the electrical core of the motor, directly determining KV value, current characteristics, efficiency and heat.

• 4.1 Wire Diameter

•    Thicker wire: stronger current carrying capacity, lower internal resistance, less heat, stronger continuous power.

•    Thinner wire: higher internal resistance, easier to heat up, lower efficiency at high throttle.

• 4.2 Number of Turns

•    Turns directly determine the KV value: more turns mean lower KV; fewer turns mean higher KV.

•    Also affects torque and current characteristics: more turns provide higher torque and lower current; fewer turns provide higher speed and higher current.

• 4.3 Winding Technology

•    Winding regularity, slot full rate and insulation treatment affect internal resistance consistency, heat dissipation and reliability.

•    Poor technology leads to uneven heating, short circuit risk and inconsistent power output.

• 4.4 Key Functions of the Winding

•    Directly defines KV value and speed range.

•    Determines internal resistance, efficiency, heat generation and throttle linearity.

•    Affects matching with propellers, ESCs and batteries.

•    In short: The winding defines characteristics, deciding the motor’s style and flight performance.

• 5. Synergistic Effect of Three Core Components on Overall Performance

•    The final motor performance is determined by the high coordination of stator, magnet and winding, rather than a single component.

•    The stator provides the power framework.

•    The magnet provides magnetic field strength.

•    The winding realizes electrical characteristics.

•    Reasonable matching of the three components results in:

•    Strong power and fast response

•    Low heat and high efficiency

•    Linear throttle and smooth control

•    Stable performance and long service life under violent flight

•    Any shortcoming will lead to:

•    Insufficient power

•    Severe heat generation

•    Unstable high-speed rotation

•    Easy demagnetization, burnout and short service life










• 6. Guiding Significance for Motor Design and Mass Production

• 6.1 Scenario-Based Design

•    Racing motors: high power density, low internal resistance, fast response

•    Freestyle motors: good linearity, sufficient torque, low heat

•    Long-range motors: high efficiency, low KV, large torque

• 6.2 Balance Between Performance and Cost

•    High-end models: high-grade magnets, low-loss stators, precision winding

•    Mass production models: optimized structure and technology for cost performance

• 6.3 Reliability Improvement

•    Optimized insulation and heat dissipation

•    Improved demagnetization and vibration resistance

•    Ensured consistency among four motors

• 7. Conclusion

•    Stator, magnet and winding are the three core pillars of FPV drone brushless motors:

•    The stator determines the power foundation and structural upper limit.

•    The magnet determines magnetic field strength and durability.

•    The winding determines electrical characteristics and efficiency.

•    Only through in-depth understanding, precise design, process optimization and systematic matching of the three core components can we develop high-performance FPV motors with strong power, low heat, fast response and long service life, truly realizing that “the motor defines the upper limit of the aircraft”.
•    In the future, the design of motors with higher power density, higher efficiency and higher reliability will continue to iterate around the three cores: stator, magnet and winding.
